This is a fully automatic garbage bag making machine, mainly used for manufacturing Z-fold drawstring garbage bags on rolls. It is computer-controlled, with servo motor controlling the length. It features print tracking, automatic counting, folding, punching functions, and fully automatic roll changing. It is a specialized equipment that is easy to operate and has high production efficiency.
| Model | RXY-800 | RXY-1000 | RXY-1200 |
| Bag Type | C or Z Fold Flat Bag Rolls With Rope | ||
| Bag Width Range | 200-600mm | 200-800mm | 200-1000mm |
| Bag Length Range | 200-1200mm | ||
| Max.Unwinding Diameter | 1000mm | ||
| Max. Winding Diameter | 180mm | ||
| Film Thickness Range | 8-100Micron | ||
| Speed | 120 Meters /min | ||
| Unwinding Device | Single | ||
| Rewinding Device | Single | ||
| Fold Up Device | Double | ||
| Roll Change | Automatic | ||
| Servo Motor | 2.0Kw | 3.0 Kw | 3.8Kw |
| Main Motor | 1.5Kw | 1.5Kw | 2.2Kw |
| Photo-cell | 1 | 1 | 1 |
| EPC ( Web Guide) | 1 | 1 | 1 |
| Power Supply | 3Phase 4lines 220V/380V/415V/440V/480V, 50/60Hz ( Custom-made ) | ||
| Air Supply | 7Kg/cm2, 700Ni/min | ||
| Total Power | 12Kw | 13Kw | 15Kw |
| Installation Size | 8.0X 1.6 X 1.7 M | 8.0 X 1.7 X 1.7 M | 8.0 X 1.8X 1.7 M |
| Labeling Function | Optional | ||
