| Model | YTB-8600 | YTB-8800 | YTB-81000 | YTB-4600 | YTB-4800 | YTB-41000 |
|---|---|---|---|---|---|---|
| Max. Width of Printing Material | 600mm | 800mm | 1000mm | 600mm | 800mm | 1000mm |
| Max. Printing Width | 560mm | 760mm | 960mm | 560mm | 760mm | 960mm |
| Suitable Material | Paper, film, no-woven fabric, foil | |||||
| Printing Color | 8色/8colors | 8色/8colors | 8色/8colors | 4色/4colors | 4色/4colors | 4色/4colors |
| Printing Speed | 10～100m/min | 10～100m/min | 10～100m/min | 10～100m/min | 10～100m/min | 10～100m/min |
| Thickness of Plate | 2.38mm | 2.38mm | 2.38mm | 2.38mm | 2.38mm | 2.38mm |
| Weight of Machine | 7000kg | 8500kg | 9000kg | 4500kg | 5000kg | 5500kg |
| Overall Dimension(L×W×H) | 5.3×1.9×3.0m | 5.3×2.1×3.0m | 5.3×2.3×3.0m | 5.3×1.9×2.5m | 5.3×2.1×2.5m | 5.3×2.3×2.5m |
Our equipment utilizes high quality materials, advanced technology and strict quality control measures.
And we provide comprehensive support and assistance to our customers, not simply selling products, but also providing cutting-edge technology and services.
